【研发定制】可充电随身wifi 大容量电池

EL988D

Chipset: Qualcomm MDM9X07

Technical Standard: FDD-LTE: Up to 150 Mbps DL and 50 Mbps UL

UMTS: Up to 42 Mbps DL and 5.76 Mbps UL(DC-HSPA+ mode)

WLAN: 802.11  b / g / n /   2.4GHz

Bands: B1/2/3/4/5/7/8/12/17/18/19/20/26/28A/28B/38/39/40/41（Optional)

UMTS: B1/2/5/8（Optional)

USB Type: Type C-USB  charge input and USB3.0 output (Power bank)

SIM/USIM Card: 4FF SIM card （Nano SIM）

Power button: Long press 3 seconds to power ON or OFF

RESET button: Reset to factory setting

Visual Indicator(LED): LED dio display working status （signal/battery/wifi）

Languages Supported: English,Chinese or more language requested

Operate System Supported: Win XP/ 7 /8/10/11, MAC OS, linux, Android （AP mode）

Win XP/ 7 /8 /10/11（USB modem ）

Battery: Build-in: NON removable

Type: Lithium ion polymer battery

 Capacity: 8000mAh WLAN: Frequency: 2.4GHz：2400MHz～2483.5MHz

Users: 1-8

Antenna: Main antenna: Build-in LTE/UMTS main antenna

DIV antenna: Build-in LTE/UMTS antenna

WLAN antenna: Build-in WiFi antenna

Form Factor: L * W * H: 156.5*70.3*16MM
